Forth and Clyde Canal (Main Line)



Information about the waterway

The Forth and Clyde Canal (Main Line) is a broad canal and is part of the Forth and Clyde Canal. It runs for 34 miles and 1 furlong through 39 locks from River Carron - Forth and Clyde Canal Junction (where it joins the River Carron) to Clyde Canal Junction (where it joins the River Cylde).

The maximum dimensions for a boat to be able to travel on the waterway are 67 feet and 2 inches long and 16 feet and 5 inches wide. The maximum headroom is 9 feet and 10 inches. The maximum draught is 6 feet.

It has junctions with the Forth and Clyde Canal (Port Dundas Branch - Main Line) at Stockingfield Junction; with the Forth and Clyde Canal (Helix Cut) at Sea Lock Basin and with the Edinburgh and Glasgow Union Canal at Union Canal Junction.

Notable features of the waterway include Falkirk Locks, Maryhill Locks, Clobberhill Locks and Kelvin Aqueduct

Originally surveyed in 1726 but no action resulted; the route was resurveyed in 1764 and received its Act of Parliament in 1768. The canal was opened in 1790 but closed in 1963. It was restored as part of the 78 million pound "Millennium Link" project, which also includes the Edinburgh and Glasgow Union canal and was re-opened by the Queen on the 24th May 2002.

The navigational authority for this waterway is Scottish Canals

Relevant publications — Waterway Maps:

River Carron - Forth and Clyde Canal Junction
Junction with the River Carron Navigation leading to the Firth of Forth
Sea Lock No 2 ¼ furlongs 0 locks
Sea Lock Basin ¾ furlongs 1 lock
Carron Cut Lock No 3 2½ furlongs 1 lock
Carron Road Bridge 5 furlongs 2 locks
Abbotshaugh Lock No 4 1 mile 2 locks
Bainsford Bridge
Canal narrows for 290yds east of the bridge
1 mile and 4¾ furlongs 3 locks
Bainsford Lock No 5 1 mile and 5 furlongs 3 locks
Falkirk Lock No 6 1 mile and 7¼ furlongs 4 locks
Falkirk Lock No 7 2 miles and 1½ furlongs 5 locks
Falkirk Lock No 8 2 miles and 2¼ furlongs 6 locks
Falkirk Lock No 9 2 miles and 3 furlongs 7 locks
Falkirk Lock No 10 2 miles and 3¾ furlongs 8 locks
Camelon Road Narrows
Possible site of an old lock No 11
2 miles and 4¼ furlongs 9 locks
Camelon Road Bridge 2 miles and 4¾ furlongs 9 locks
Falkirk Lock No 11 2 miles and 5 furlongs 9 locks
Falkirk Lock No 12 2 miles and 5½ furlongs 10 locks
Falkirk Lock No 13 2 miles and 6¼ furlongs 11 locks
Falkirk Lock No 14 2 miles and 6¾ furlongs 12 locks
Falkirk Lock No 15 2 miles and 7¾ furlongs 13 locks
Falkirk Top Lock No 16 3 miles and ½ furlongs 14 locks
Falkirk Top Lock Winding Hole 3 miles and ¾ furlongs 15 locks
Union Inn (Falkirk)
Canalside
3 miles and 1 furlong 15 locks
Union Canal Junction Footbridge 4 miles and ½ furlongs 15 locks
Union Canal Junction
Junction of Forth and Clyde and Edinburgh and Glasgow Union Canals
4 miles and ¾ furlongs 15 locks
Union Canal Junction Railway Aqueduct 4 miles and 1 furlong 15 locks
Camuirs Burn Aqueduct 4 miles and 3¼ furlongs 15 locks
Rowantree Burn Aqueduct 4 miles and 5¾ furlongs 15 locks
Bonnybridge Aqueduct No 4 5 miles and 7¼ furlongs 15 locks
Bonnybridge Lift Bridge 5 miles and 7½ furlongs 15 locks
Seabegs Aqueduct 6 miles and 4¾ furlongs 15 locks
Underwood Aqueduct 7 miles and ½ furlongs 15 locks
Underwood Lock No 17 7 miles and 2½ furlongs 15 locks
Castlecary Lock No 18 7 miles and 7 furlongs 16 locks
Castlecary Lock No 19 8 miles and 1¼ furlongs 17 locks
Castlecary Bridge 8 miles and 2½ furlongs 18 locks
Cumbernauld Road Bridge 8 miles and 3 furlongs 18 locks
Red Burn Aqueduct 8 miles and 4¾ furlongs 18 locks
Wyndford Bridge No 14 9 miles and 1¾ furlongs 18 locks
Wyndford Lock No 20 9 miles and 1¾ furlongs 18 locks
Wyndford Lock Narrows 9 miles and 2½ furlongs 19 locks
Wyndford Lock Winding Hole 10 miles and 1½ furlongs 19 locks
Craigmarloch Basin 11 miles and 4¼ furlongs 19 locks
Craigmarloch Bridge No 15 11 miles and 6 furlongs 19 locks
Auchinstarry Winding Hole 12 miles and 2¾ furlongs 19 locks
Auchinstarry Basin 12 miles and 6½ furlongs 19 locks
Auchinstarry Bridge 12 miles and 7¼ furlongs 19 locks
Auchinstarry Bridge (demolished) 12 miles and 7¾ furlongs 19 locks
Twechar Bridge 14 miles and 4½ furlongs 19 locks
Twechar Aqueduct
also called Shirva Aqueduct
15 miles and 1¼ furlongs 19 locks
Tintock Aqueduct No 9 15 miles and 7¾ furlongs 19 locks
Auchendavie Aqueduct 16 miles and 3½ furlongs 19 locks
Hillhead Road Bridge 17 miles and 4½ furlongs 19 locks
Luggiebank Road Winding Hole 17 miles and 4¾ furlongs 19 locks
Luggie Aqueduct No 11 17 miles and 5¾ furlongs 19 locks
New Lairdsland Road Bridge 17 miles and 6¼ furlongs 19 locks
Townhead Bridge 17 miles and 7¼ furlongs 19 locks
Kirkintilloch Marina 18 miles and 1½ furlongs 19 locks
Kirkintilloch Footbridge
Unusual footbridge
18 miles and 2 furlongs 19 locks
Glasgow Road Bridge 19 miles and 2½ furlongs 19 locks
Hungryside Bridge 20 miles and ½ furlongs 19 locks
Cadder Bridge 20 miles and 6¾ furlongs 19 locks
Balmuildy Bridge 21 miles and 5 furlongs 19 locks
Lambhill Bridge 23 miles and 5 furlongs 19 locks
Lambhill Railway Aqueduct No 12 24 miles and ¾ furlongs 19 locks
Halloween Pend Aqueduct 24 miles and ¾ furlongs 19 locks
Stockingfield Narrows 24 miles and 4½ furlongs 19 locks
Stockingfield Junction
Junction with the Port Dundas branch
24 miles and 4¾ furlongs 19 locks
Stockingfield Junction Aqueduct No 14 24 miles and 5 furlongs 19 locks
Maryhill Road Aqueduct No 15 24 miles and 7½ furlongs 19 locks
Maryhill Top Lock No 21 25 miles and ¾ furlongs 19 locks
Maryhill Lock No 22 25 miles and 1¼ furlongs 20 locks
Maryhill Lock No 23 25 miles and 1½ furlongs 21 locks
Maryhill Lock No 24 25 miles and 1¾ furlongs 22 locks
Maryhill Bottom Lock No 25 25 miles and 2¼ furlongs 23 locks
Kelvin Aqueduct (eastern end) 25 miles and 2½ furlongs 24 locks
Kelvin Aqueduct (western end) 25 miles and 3 furlongs 24 locks
Cleveden Road Bridge 25 miles and 5¼ furlongs 24 locks
Gas Board Aqueduct No 17 25 miles and 5¼ furlongs 24 locks
Stobcross Rail Aqueduct 25 miles and 7¼ furlongs 24 locks
Temple Lock No 26 26 miles and ¼ furlongs 24 locks
Temple Rail Aqueduct 26 miles and ¾ furlongs 25 locks
Lock 27 PH (Glasgow)
Canalside
26 miles and ¾ furlongs 25 locks
Temple Lock No 27 26 miles and 1 furlong 25 locks
Temple Road Bridge 26 miles and 1½ furlongs 26 locks
Howth Drive Bridge 26 miles and 2½ furlongs 26 locks
Old Farm Road Bridge 26 miles and 4½ furlongs 26 locks
Westerton Footbridge 27 miles and ¾ furlongs 26 locks
Clobberhill Top Lock No 28 27 miles and 3¼ furlongs 26 locks
Clobberhill Middle Lock No 29 27 miles and 3¾ furlongs 27 locks
Clobberhill Bottom Lock No 30 27 miles and 4¼ furlongs 28 locks
Clobberhill Lock No 31 27 miles and 6 furlongs 29 locks
Clobberhill Lock No 32 27 miles and 6½ furlongs 30 locks
Great Western Road Bridge (north) 28 miles and ½ furlongs 31 locks
Great Western Road Bridge (south) 28 miles and ¾ furlongs 31 locks
Bard Avenue Footbridge 28 miles and 2½ furlongs 31 locks
Boghouse Top Lock No 33 28 miles and 4 furlongs 31 locks
Boghouse Middle Lock No 34 28 miles and 4¾ furlongs 32 locks
Boghouse Bottom Lock No 35 28 miles and 5¾ furlongs 33 locks
Boghouse Lock No 36 28 miles and 7¼ furlongs 34 locks
Dunreath Avenue Bridge 28 miles and 7¾ furlongs 35 locks
Kirkwood Avenue Footbridge 29 miles and 1¾ furlongs 35 locks
Argyll Road Bridge 29 miles and 7½ furlongs 35 locks
Seaforth Road Footbridge 30 miles and ½ furlongs 35 locks
Seaforth Road Covered Footbridge 30 miles and 1 furlong 35 locks
Seaforth Road and A8014 Road Bridges 30 miles and 1¼ furlongs 35 locks
Boquhanran Railway Aqueduct No 21 30 miles and 6 furlongs 35 locks
Boquhanran Road Aqueduct No 22 30 miles and 6½ furlongs 35 locks
Trafalgar Street Footbridge 30 miles and 7½ furlongs 35 locks
Dalmuir Drop Lock and Bridge
Constructed during the restoration of the canal to get the navigation under an existing bridge
31 miles and 1¼ furlongs 35 locks
Duntocher Burn Aqueduct 31 miles and 4¼ furlongs 36 locks
Farm Road Bascule Footbridge 31 miles and 4½ furlongs 36 locks
Ferry Road Swing Bridge 32 miles and 5¼ furlongs 36 locks
Erskine Bridge 32 miles and 6 furlongs 36 locks
Dalnottar Lock No 37 32 miles and 6¼ furlongs 36 locks
Portpatrick Road Bascule Footbridge 33 miles and 2¼ furlongs 37 locks
Bowling Lock Wharf 33 miles and 5¾ furlongs 37 locks
Bowling Lock No 38 33 miles and 6¼ furlongs 37 locks
Bowling Lock Basin 33 miles and 6½ furlongs 38 locks
Basin Bascule Footbridge 33 miles and 6¾ furlongs 38 locks
Basin Railway Bridge 33 miles and 6¾ furlongs 38 locks
Bowling Basin 33 miles and 7¼ furlongs 38 locks
Bowling Basin Sea Lock 33 miles and 7¾ furlongs 38 locks
The Bay Inn
A five minute walk over the railway bridge from the basin mooorings, then east along Dumbarton Road.
34 miles and ¼ furlongs 39 locks
Clyde Canal Junction
Junction of the River Clyde and the Forth and Clyde Canal
34 miles and 1 furlong 39 locks
