Birmingham Canal Navigations (Old Main Line)
The Birmingham Canal Navigations (Old Main Line) is a narrow canal and is part of the Birmingham Canal Navigations.
It runs for 6 miles and 4 furlongs through 3 locks from Tipton Factory Junction (where it joins the Birmingham Canal Navigations (Main Line)) to Smethwick Junction (where it joins the Birmingham Canal Navigations (Main Line)).
The maximum dimensions for a boat to be able to travel on the waterway are 72 feet long and 7 feet wide. The maximum headroom is not known. The maximum draught is not known.
It has junctions with the Birmingham Canal Navigations (Titford Canal - Main Line) at Oldbury Junction; with the Birmingham Canal Navigations (Spon Lane Locks Branch) at Spon Lane Junction; with the Birmingham Canal Navigations (Engine Arm) at Engine Arm Junction; with the Birmingham Canal Navigations (Gower Branch) at Brades Hall Junction and with the Birmingham Canal Navigations (Dudley Canal No 1 - Birmingham End) at Tipton Junction.
Notable features of the waterway include Smethwick Locks and Summit Tunnel
The navigational authority for this waterway is Canal & River TrustRelevant publications — Waterway Maps:
- Waterway Routes 01M - England and Wales Map
- Waterway Routes 88M - Stourport Ring Map (Downloadable)
- Waterway Routes 85M - Black Country Ring Map (Downloadable)
- Waterway Routes 38M - Birmingham Canal Navigations (BCN) Map (Downloadable)
Relevant publications — Waterway Guides:
- Collins Nicholson Waterways Guides No 2 - Severn, Avon & Birmingham
- Pearson's Canal Companion: Stourport Ring; Black Country Canals; Birmingham Canal Navigations
Relevant publications — Waterway Histories:
| Tipton Factory Junction Junction of BCN Old and New Main Lines. Access to the Barge & Barrel PH |
|||
| Former Malthouse Stables Now a water activity centre |
¼ furlongs | 0 locks | |
| Tipton Visitor Moorings | 1 furlong | 0 locks | |
| John the Lock Moorings - Friends of Tipton Cut | 3½ furlongs | 0 locks | |
| The Fountain Inn | 4½ furlongs | 0 locks | |
| Owen Street Bridge | 4¾ furlongs | 0 locks | |
| Coronation Gardens Moorings | 5¼ furlongs | 0 locks | |
| Tipton Green Junction Junction with the closed Tipton Green and Toll End Communication Canals |
5½ furlongs | 0 locks | |
| Tipton Green Bridge The new bridge carrying Park Lane West over the canal is right next to the old bridge. The gap between the bridges is in the verge. |
6 furlongs | 0 locks | |
| Tipton Junction Junction of Dudley Canal No 1 (Lord Wards Canal) with the BCN Old Main Line |
1 mile | 0 locks | |
| Pitchfork Bridge | 1 mile and 1¼ furlongs | 0 locks | |
| Pitchfork Pipe Bridge | 1 mile and 1¼ furlongs | 0 locks | |
| Coneygree Bridge | 1 mile and 2¾ furlongs | 0 locks | |
| Randalls Bridge | 1 mile and 4¾ furlongs | 0 locks | |
| Dudley Port Bridge | 1 mile and 5¼ furlongs | 0 locks | |
| Tividale Quays Basin | 1 mile and 6¼ furlongs | 0 locks | |
| Kier's Bridge Arm (closed) | 1 mile and 7 furlongs | 0 locks | |
| Kiers Bridge | 1 mile and 7¼ furlongs | 0 locks | |
| Tividale Aqueduct over Netherton Tunnel Branch |
2 miles | 0 locks | |
| Gilberts Bridge | 2 miles and 1¼ furlongs | 0 locks | |
| Site of Hainge Navigation leading to Hainge Cutting Infilled and built upon |
2 miles and 2 furlongs | 0 locks | |
| Dudley Road West Bridge | 2 miles and 2¼ furlongs | 0 locks | |
| Tividale Toll Stop | 2 miles and 3 furlongs | 0 locks | |
| Site of Tile Cutting Infilled and built upon |
2 miles and 3¼ furlongs | 0 locks | |
| Site of Russel Cutting Infilled and built upon |
2 miles and 3¾ furlongs | 0 locks | |
| Site of Shinwell Cutting Infilled |
2 miles and 4 furlongs | 0 locks | |
| Fishers Bridge | 2 miles and 4½ furlongs | 0 locks | |
| Brades Hall Colliery Basin (closed) Infilled |
2 miles and 4¾ furlongs | 0 locks | |
| Brades Hall Junction Junction of Gower Branch with BCN Old Main Line and Gower Basin |
2 miles and 4¾ furlongs | 0 locks | |
| Site of City Road Cutting Infilled |
2 miles and 5 furlongs | 0 locks | |
| Brades Cable Bridge | 2 miles and 7 furlongs | 0 locks | |
| Brades Bridge | 2 miles and 7 furlongs | 0 locks | |
| Site of St James's Cutting | 2 miles and 7¾ furlongs | 0 locks | |
| Site of Brades Loop (northwest) Infilled and built upon |
3 miles and ½ furlongs | 0 locks | |
| Site of Junction with Oldbury Loop (northwest) and Brades Loop (southeast) Both loops infilled |
3 miles and 1½ furlongs | 0 locks | |
| High Bridge (Oldbury) | 3 miles and 2¾ furlongs | 0 locks | |
| Site of Littlefields Cutting Infilled and built upon |
3 miles and 3½ furlongs | 0 locks | |
| Whimsey Bridge (west) | 3 miles and 3¾ furlongs | 0 locks | |
| Whimsey Bridge (east) | 3 miles and 4 furlongs | 0 locks | |
| Site of Nail Works Basins Infilled |
3 miles and 4¼ furlongs | 0 locks | |
| Site of Glass Works Basin | 3 miles and 4½ furlongs | 0 locks | |
| Valencia Wharf and Oldbury Loop Junction (southeast) Infilled |
3 miles and 4½ furlongs | 0 locks | |
| Site of Valentia Arm Junction Infilled and partly build upon |
3 miles and 4¾ furlongs | 0 locks | |
| Seven Stars Bridge | 3 miles and 5¼ furlongs | 0 locks | |
| Seven Stars Arm (closed) | 3 miles and 5½ furlongs | 0 locks | |
| Junction of the Houghton Branch (Chemical Arm) (closed) Junction of the Houghton Branch and the Old Main Line |
3 miles and 6 furlongs | 0 locks | |
| Oldbury Wharf Stanked off by I.C.I. Ltd. May 1950 |
3 miles and 6 furlongs | 0 locks | |
| Site of Oldbury Branch Railway Bridge Oldbury Goods Station - Oldbury and Langley Green Line |
3 miles and 6¼ furlongs | 0 locks | |
| Stone Street Bridge | 3 miles and 6¾ furlongs | 0 locks | |
| Stone Street Bridge Wharf | 3 miles and 6¾ furlongs | 0 locks | |
| M5 Motorway Viaduct (Oldbury) Motorway bridges about 400 yards of the canal |
3 miles and 7 furlongs | 0 locks | |
| Oldbury Junction Bridge | 3 miles and 7 furlongs | 0 locks | |
| Oldbury Junction Junction of Old Main Line and Titford Canal |
3 miles and 7¼ furlongs | 0 locks | |
| Manchester Street Bridge | 3 miles and 7¾ furlongs | 0 locks | |
| Anchor Bridge (Oldbury) | 4 miles | 0 locks | |
| Blakeley Hall Bridge Site of Toll House |
4 miles and 2¼ furlongs | 0 locks | |
| Stewart Turnover Bridge | 4 miles and 3 furlongs | 0 locks | |
| Site of Spon Lane Basin Infilled |
4 miles and 3 furlongs | 0 locks | |
| Stewart Railway Bridge | 4 miles and 3 furlongs | 0 locks | |
| Stewart Aqueduct | 4 miles and 3¼ furlongs | 0 locks | |
| Spon Lane Junction Junction of Old Main Line and Spon Lane Locks Branch |
4 miles and 4 furlongs | 0 locks | |
| Site of Stour Valley Works Basin Infilled |
4 miles and 4¼ furlongs | 0 locks | |
| Spon Lane Bridge | 4 miles and 5 furlongs | 0 locks | |
| M5 Motorway over Old Main Line (western end) | 4 miles and 6 furlongs | 0 locks | |
| M5 Motorway over Old Main Line (eastern end) | 4 miles and 7¾ furlongs | 0 locks | |
| Summit Rail Bridge | 5 miles and 2½ furlongs | 0 locks | |
| Summit Bridge | 5 miles and 2½ furlongs | 0 locks | |
| Summit Tunnel (northwestern entrance) | 5 miles and 2½ furlongs | 0 locks | |
| Summit Tunnel (southeastern entrance) Telford Way (A4168) crosses the tunnel |
5 miles and 3 furlongs | 0 locks | |
| New Smethwick Pumping Station (old line) Galton Valley Canal Heritage Centre |
5 miles and 5¾ furlongs | 0 locks | |
| Brasshouse Lane Bridge | 5 miles and 6 furlongs | 0 locks | |
| Engine Arm Junction | 6 miles | 0 locks | |
| Smethwick Top Lock No 1 | 6 miles and ½ furlongs | 0 locks | |
| Smethwick Top Lock Footbridge | 6 miles and ½ furlongs | 1 lock | |
| Smethwick Middle Lock No 2 | 6 miles and 1½ furlongs | 1 lock | |
| Site of Smethwick Bottom Lock Wharf | 6 miles and 2 furlongs | 2 locks | |
| Smethwick Bottom Lock No 3 | 6 miles and 2¼ furlongs | 2 locks | |
| Pope Bridge | 6 miles and 2½ furlongs | 3 locks | |
| Woodford Iron Works Basin Infilled |
6 miles and 3¾ furlongs | 3 locks | |
| Smethwick Towing Path Bridge | 6 miles and 3¾ furlongs | 3 locks | |
| Smethwick Junction Junction of BCN Old and New Main Lines |
6 miles and 4 furlongs | 3 locks |
